armored field light is double track
(gmdkau-2b6-2.5-bl)
product description
armored field light double line is sheathed communication optical cable designed for military field and complexcombat environment rapidly and repeatedly and temporary wiring. the cable with anti zhang liqiang, anti pressure ability, good softness, bending resistance, resistance to wear, flame retardant, oil, the characteristics oftemperature wide application range etc.. applicable to military field communication system fast wiring or repeatedretraction; radar, aviation and ship routing; occasions oil, mines, ports, televised, communication line repair of harsh conditions.
product features
◆ small stainless steel hose protection, has good mechanical properties；
◆ thermoplastic polyurethane elastomer sheath for cable provides structural stability and wear resistance, good oil resistance, low temperature flexibility performance；
◆ fiber flexibility is excellent, easy to use；
use
◆ military communication；
◆ oil, natural gas, coal mine, geological exploration and other communication；
◆ broadcast television, temporary communication system；
the main parameters
|
project |
project |
parameters or description |
|
size appearance |
the outer diameter of the optical cable |
2.6mm士0.1mm |
|
color |
black |
|
|
standard length |
1000m |
|
|
material science |
optical fiber |
refractive index gradient glass fiber |
|
tensile member |
america dupont kevla kevlar |
|
|
stainless steel hose |
sus201 |
|
|
the outer sheath |
flame retardant tpu |
|
|
optical fiber |
optical fiber type |
g657a2 bending type dispersion unshifted single-mode optical fiber |
|
the fiber core |
2core |
|
|
optical fiber color |
white or blue |
|
|
optical properties |
attenuation |
≤0.4 db/km(1310nm) |
|
≤0.3 db/km(1550nm) |
||
|
permissible tensile force |
1200n-1500n |
|
|
allow the compressed stress |
2000n-3200n/10cm |
|
|
bending radius |
dynamic 30mm |
|
|
static 60mm |
||
|
environmental characteristics |
working temperature |
-50℃~ 85℃ |
|
storage temperature |
-50℃~ 85℃ |
|
|
sheathed flame retardant |
flame retardant grade |
ul94v-0 |
|
weight |
cable net |
8.0kg/1000m |
|
the reference standard |
countries, standard |
gb/t 7424.1-2003；yd/t 1258.4-2005 |
|
gjb 1428b-2009 （note: some reference） |
||
|
packing |
packaging |
the wooden shaft |
